55 inch all in one pc large lcd display multi touch screen floor stand digital signage

FOB Reference Price:Get Latest Price
US $500-2,000 / Piece | 1 Piece/Pieces advertising display standalone (Min. Order)
Supply Ability:
3500 Piece/Pieces per Week advertising display stand
Port:
Shenzhen
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
TYALUX
Model Number:
TYL-HGM550LA(N)04
Type:
TFT
Application:
Indoor
Panel Size:
55Inch
Max Resolution:
Full HD 1080P
Viewing Angle:
178°/178°
Pixel Pitch:
0.73mm (H)x0.73mm (V)
Color:
16.7M
Contrast Ratio:
4000:1
Brightness:
450cd/m2
Response Time:
5ms
Input Voltage:
AC 100-240V / 50-60Hz
Product name:
55 Inch Standalone Digital Signage
Extermal Memory:
SATA/USB/SD/CF card
Viewable area:
1207(H)x678(V)mm
Max Consumption:
170W
CPU:
1.5G Dual Core
RAM:
1G,2G is optional
Standby Power:
0.3W
Operating System:
Android 4.4(up to 5.1)
Packaging & Delivery
Packaging Details
Carton Box, Wooden Box, Flight Case
Delivery Time
Shipped in 7 days after payment

55 inch all in one pc large lcd display multi touch screen floor stand digital signage

Product Description



Working Principle of Digital Signage

Digital content can be created easily via digital signage which allow advertisers to combine audio, video, image and interactivity by themselves. Digital contents displayed on the signage is presented in one of the following formats:

♦ Text - Scrolling text. Either scrolling text, or text dynamically updated via external newsfeed source.

♦ Images - Scrolling images, usually in the format of digital advertisement posters.

♦ Video - Usually in the format of commercial TV advertisements.

♦ Interactive interfaces - Combining with Touch Screen and which allows two-way communications with the users. It helps to engage users and also helps advertisers to gain insight in customer behaviors.



Features of TYALUX Digital Signage

 Based on Android 4.4 system(up to 5.1), all the android application apk, software automatic restoration supported.
♦ Real time management and controlling, browser, breakpoint upload download, multi-mode upload supported.
♦ Updating programs (video, pictures. texts,PPT etc.) through the internet supported.
♦ Auto power on/off, electronic clock & date supported.
♦ Split Screen and fixed templated display setting supported.
♦ Setting IP address, working time and working day supported.
♦ 1080P full HD programs display supported.
♦ WLAN & LAN long-distance setting play/sleep/reboot etc..function supported.
♦ Display contents cryptographic protection supported (optional).
♦ Cable network, wifi, 3G, 4G touch screen, motion senor and inner camera setting supported (optional).

Available in a wide range of sizes: 43”,49",55” and 65”, each display has built-in speakers and comes with a remote control.



Specification of Digital Signage

Specification for PanelSpecification for Android main board
Screen size55" TFT LCD PanelCPU

1.5GHz, Dual Core

1.8GHZ, Qual Core

Touch screenOptionalInfrared remote controlsupport
Max. Resolution1920x1080RAM1G,2G is optional
Viewing angle178°/178°Internal MemoryNAND FLASH 4G
Color16.7MExternal MemorySATA/USB/SD card/CF card
Brightness450cd/m2Resolution1080P (1920x1080)
Contrast ratio4000:1Operating systemAndroid 4.4(up to 5.1)
Response time5msPlay modeCirculation, timing, inter-cutting etc.
Viewable area1207(H)x678(V)mmNetworkEthernet, wifi, 3G,4G is optional
Dot Pitch0.73(H)x0.73(V)mmVideo formatCompatible for SD card and CF card
Working powerAC100-240V 50/60HzSD cardwmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc.
Speaker power consumption10WPicture formatBMP, JPEG, PNG, GIF
Max power consumption240WNetworking protocolTCP IP/PPPOE/ICMP/DHCP/DNS/FTP/HTTP
Standby power consumption0.3WUSB2.0 port2x USB HOST external mouse and
keyboard
Working humidity10%-90% (Without dew)Ethernet1x RJ45, 10M/100M optional
Working temperature0℃-40℃LVDS / output1
Storage temperature-20℃-60℃HDMI output1
RemarksAV outputCVBS AV output (L/R)
built in double power amplifier
Installation typeFloor standingVGA output1
DesigniPhone appearanceReal time clockYes
Comes with accessoryUser Manual x1Timing switchYes
Remote control x1System upgradeUSB upgrade and network upgrade supported
CD x1SafetySafety lock design
Floor standing installation kitsWorking temperature0℃-40℃
